the patented technology strabiscan brings you​

a new quality to pathology detection
and strabismus management

a key to Precision in Every Diagnosis

The device is equipped with a complex optical system and a system of cameras that track eye movements.

Strabiscan® uses the technique of alternating and cyclical projection of graphic patterns on the screen, synchronous occlusion of the eye, analysis, and recording of compensatory eye movements.

It takes into account the individual pupillary distance and distortions caused by the patient’s refractive errors.

the patented technology strabiscan brings you​

a new quality to pathology detection
and strabismus management

fully automatic measurement

Diagnosis of vertical and horizontal strabismus.

Unparalleled Precision

StrabiScan® uses an advanced eye-tracking system, ensuring accurate measurement of eye deviation angles.

rapid diagnosis

With automated procedures and intuitive operation, diagnosis takes just a few minutes.

Patient Comfort​

The examination is non-contact and non-invasive, ensuring comfort even for the youngest patients.

Comprehensive Documentation​

StrabiScan® generates detailed reports, facilitating progress tracking.

technical specification

physical dimensions

System dimensions

H=250mm [20.5”], W=530mm [21.8”], L=630mm [25”]

System weight

30 kg [66lbs]

chinrest

Height adjustment

Up to 2.4”

electrical requirements

100-240VAC 50/60Hz; system power consumption < 200VA

laser module

Laser media

Doubled Q-switched Nd: YAG

Laser energy (range)

0.3 – 2.6 mJ

Pulse duration

3 ns

Spot size

400 μm

Laser frequency

50 Hz with automated approval for each pulse

Aiming/Ranging Beams

CW diode laser; 635, 650nm; 150μW maximum – CDRH Classification /IEC 60825; Classification – I/Class 1

Treatment Beam

CDRH Classification /IEC 60825;
Classification – IIIB/Class 3B

Laser Safety Eyewear

D LB4 R LB6 for 532 nm

StrabiScan sp. z o.o.

Przemysłowa 17, 32-083 Balice POLAND
